Zortrax Apoller SVS Device

Zortrax Apoller SVS Device

NT$280,000
NT$238,000
{{shoplineProductReview.avg_score}} {{'product.product_review.stars' | translate}} | {{shoplineProductReview.total}} {{'product.product_review.reviews' | translate}}
{{amazonProductReview.avg_rating}} {{'product.product_review.stars' | translate}} | {{amazonProductReview.total_comment_count}} {{'product.product_review.reviews' | translate}}
{{ title.name_translations | translateModel }} : {{variationName[$index] | translateModel}}
Quantity
Quantity
The maximum quantity per submit is 99999
This quantity is invalid, please enter a valid quantity.
Sold Out

Not enough stock.
Your item was not added to your cart.

Not enough stock.
Please adjust your quantity.

Limit {{ product.max_order_quantity }} per order.

Only {{ quantityOfStock }} item(s) left.

Please message the shop owner for order details.

Description

A smart and safe device for automated vapor smoothing

Zortrax Apoller is a smart vapor smoothing device that automatically removes visible layering from FDM 3D prints. It works works with both acetone and MEK. The smoothing process is fully automated and run by proprietary algorithms managing temperature, pressure, and concentration of solvent's vapors at all times. First, the model has to be placed inside the smoothing chamber. Once this is done, the chamber is heated enough to vaporize the solvent deposited in a sink below the glass tray. Vapors are then circulated spiraling upwards to evenly cover the model. Solvent's vapors condensate on surfaces leaving them with a glossy or mat finish, depending on the filament used. Finally, Zortrax Apoller dries the prints out to make them ready to use straight out of the chamber. Combined weekly output of 4 typical FDM 3D printers can be automatically smoothed within one day. Safety systems have been designed to meet the high standards required by the ATEX 2014/34/EU Directive regulating the equipment intended for explosive atmospheres.

Every unit requires an annual inspection conducted by the Zortrax Authorized Service to keep the ATEX certification valid and ensure safe operation of the device.


Compatible filaments: ABS, ASA, HIPS

Compatible solvents: Acetone, Butanone (MEK)

Compatible Zortrax filaments: Z-ABS, Z-HIPS, Z-ULTRAT, Z-ULTRAT Plus, Z-ASA Pro

Specification

Device

Build volume
300 x 250 x 250 mm (11.8 x 9.8 x 9.8 in)
Connectivity
Wi-Fi, Ethernet, USB
Operating system
Android
Processor
Quad Core
Touchscreen
4'' IPS 800 x 480
Solvent compatibility
Aceton, MEK
Available materials
Z-ABS, Z-ULTRAT, Z-ULTRAT Plus, Z-ASA Pro, Z-HIPS
External materials
ABS, ASA, HIPS

Weight and physical dimensions

Device (W x D x H)
671 x 396 x 388 mm (26.4 x 15.6 x 15.3 in)
Internal dimensions
340 x 270 x 260 mm (13.4 x 10.6 x 10.2 in)
Device weight
30 kg (66 lb)

Process

Maximum working temperature
90° C (194° F)
Minimum working temperature
-20° C (-4° F)
Minimum absolute working pressure
0.4 bar
Ambient operation temperature
15 – 30° C (59 – 86° F)
Storage temperature
0 - 35° C (32 - 95° F)

Electrical

AC input
110 V ~ 13.6 A 50/60 Hz
Power supply parameters
24 V DC @ 14 A, 500 W
Maximum power consumption
1500 W

In the box

Device, Starter Kit

Additional information

All information contained in this brochure and specification is subject to change without notice.
