Zortrax M200 Plus 3D Printer + HEPA Cover

Zortrax M200 Plus 3D Printer + HEPA Cover

NT$106,000
NT$96,000
{{shoplineProductReview.avg_score}} {{'product.product_review.stars' | translate}} | {{shoplineProductReview.total}} {{'product.product_review.reviews' | translate}}
{{amazonProductReview.avg_rating}} {{'product.product_review.stars' | translate}} | {{amazonProductReview.total_comment_count}} {{'product.product_review.reviews' | translate}}
Quantity Product set quantity

Buy Together and Save More (At most {{ addItemQuantity }} item(s))

魔速洗清洗劑/3D列印清洗劑/樹脂清洗劑 - 1KG(適用SLA/DLP/LCD光固化3D列印成品)
Sale NT$315
凡購買Zortrax列印機，皆可加購8000得一台Mayku FormBox真空成型機(原價23,800)
Sale NT$8,000

The maximum quantity per submit is 99999
This quantity is invalid, please enter a valid quantity.
Sold Out

Not enough stock.
Your item was not added to your cart.

Not enough stock.
Please adjust your quantity.

Limit {{ product.max_order_quantity }} per order.

Only {{ quantityOfStock }} item(s) left.

Please message the shop owner for order details.

Description

Zortrax M200 Plus & HEPA Cover

M200 Plus 3D Printer and Zortrax HEPA Cover.

A bundle of 3D printer and filtering device. Side Covers included.


Zortrax M200 Plus features


  • Wi-Fi and Ethernet connectivity
  • Material End Detection
  • Upgraded extruder compatible with semi-flexible filaments
  • Upgraded cooling system (double fan and extruder cooling)


Zortrax HEPA Cover features


  • Maintains stable temperature inside the printing chamber to reduce warping of ABS-based materials
  • Carbon filter eliminates unpleasant smells
  • HEPA filter catches over 99% of 3D printing emissions, including ultra fine particles
  • Electric fan with regulated speed

Description

Zortrax M200 Plus with Zortrax HEPA Cover


Zortrax HEPA Cover is a filtering device compatible with Zortrax M200 Plus wireless 3D printer. Based on the award winning Zortrax M200, Zortrax M200 Plus has been designed to work in large 3D printing farms. Zortrax HEPA Cover perfectly complements the M200 Plus in this application. Having the two working together, it's possible to maintain higher temperatures inside the printing chamber which significantly reduces shrinkage of ABS-based materials. HEPA filters catch over 99% of 3D printing emissions, including ultra fine particles, while carbon filters work to reduce unpleasant smells to ensure safe and smooth operation of a 3D printing farm.

Specification

3D printer features

Build volume
200 x 200 x 180 mm (7.9 x 7.9 x 7.1 in)
Material container
Spool
Material diameter
1,75 mm (0.069 in)
Nozzle diameter
0,4 mm (0.016 in)
Support
Mechanically removed - printed with the same material as the model
Extruder
Single (upgraded for more demanding materials)
Extruder cooling system
Radial fan cooling the extruder block
Hotend
Redesigned (v3), new geometry of the nozzle
Material endstop
Mechanical
Platform
Perforated, heated, equipped with Pogo pins
Connectivity
WI-FI, USB, Ethernet,
Operating system
Android
Processor
Quad Core
Touchscreen
4"
Camera
Yes, 640 x 480
Available materials
Z-ULTRAT, Z-HIPS, Z-GLASS, Z-PETG, Z-ESD, Z-PCABS, Z-ABS, Z-ASA Pro, Z-PLA Pro
External materials
Applicable
In the box
3D printer, spool of material, side covers, USB, build platform, heatbed cable, power cable, spool holder, material guide, quick start guide, Z-SUITE 2 software, starter kit

Zortrax HEPA Cover parameters

HEPA cover dimensions****
426 x 357 x 230 mm (16.8 x 14 x 9 in)
Weight
1,95 kg (4.3 lbs)
Box dimensions
405 x 380 x 255 mm (15.9 x 15 x 10 in)
Total weight of the box
3,35 kg (7.4 Ibs)
Odors filter
Carbon filter
Particle filter
HEPA
HEPA filter ffficiency
Over 99%
Mains voltage
100-240 VAC, 0.7 A 50/60 Hz
Power supply
12 VDC, 0.5 A (min)
Average energy consumption
6 W
Compatible with
Zortrax M200 / Zortrax M200 Plus
In the box
Zortrax HEPA Cover, filter module (electric fan with regulated speed, HEPA filter, carbon filter), power supply unit, front door, user's manual

Printing

Technology
LPD (Layer Plastic Deposition) – depositing melted material layer by layer onto the build platform
Layer resolution
90-390 microns
Minimal optimal wall thickness
800 microns
Minimal wall thickness
400 microns
Dimensional accuracy
+/- 0.2%**
Angle accuracy
+/- 0.2%***
X/Y positioning accuracy
1.5 micron
Z-axis single step
1.25 micron
Platform levelling
Automatic measurement of platform points' height
Maximum platform temperature
105 ˚C (221 °F)
Maximum printing temperature (extruder)
290 ˚C (554 °F)
Ambient operation temperature
20 - 30 ˚C (68 - 86 °F)
Storage temperature
0 - 35 ˚C (32 - 95 ˚F)
AC input
110 V ~ 5.9 A 50/60 Hz 240 V ~ 2.5A 50/60 Hz
Power supply parameters
24 V DC @ 14 A, 500 W
Maximum power consumption
320 W

Weight and physical dimensions

3D printer (W x D x H)
350 x 360 x 505 mm (13.8 x 14.2 x 19.9 in)
With a spool
350 x 430 x 505 mm (13.8 x 16.9 x 19.9 in)
Shipping box
470 x 480 x 570 mm (18.5 x 18.9 x 22.4 in)
Shipping weight
26 kg (57.3 lb)
Printer weight*
16 kg (32 lb)

Software

Software bundle
Z-SUITE 2
Supported file types
.stl, .obj, .dxf, .3mf
Supported operating systems
Mac OS X / Windows 7 and newer versions

Additional information

Each delivered printer may have worked up to 50 hours during the quality control test prints.

* The weight includes: the device with the platform, power cable and spool holder installed. It does not include the material spool.

** It should be noted that the model’s dimensions strongly depend on the technical condition of the printer as well as the shape, form and size of a print, the material used and the printing process conditions. The Z-axis accuracy does not include a tolerance of +/- one layer. Bear in mind errors of measurement and measuring equipment.

*** measurements were taken with an angle of 90˚.

**** Dimensions of an assembled, ready to use device.
