Zortrax M300 Dual 3D printer + Hepa Cover

Zortrax M300 Dual 3D printer + Hepa Cover

NT$230,000
NT$191,500
{{shoplineProductReview.avg_score}} {{'product.product_review.stars' | translate}} | {{shoplineProductReview.total}} {{'product.product_review.reviews' | translate}}
{{amazonProductReview.avg_rating}} {{'product.product_review.stars' | translate}} | {{amazonProductReview.total_comment_count}} {{'product.product_review.reviews' | translate}}
{{ title.name_translations | translateModel }} : {{variationName[$index] | translateModel}}
Quantity
Quantity
The maximum quantity per submit is 99999
This quantity is invalid, please enter a valid quantity.
Sold Out

Not enough stock.
Your item was not added to your cart.

Not enough stock.
Please adjust your quantity.

Limit {{ product.max_order_quantity }} per order.

Only {{ quantityOfStock }} item(s) left.

Please message the shop owner for order details.

Description

3D Printers

Zortrax M300 Dual

Professional large volume dual-extrusion 3D printer.

Device features:


  • Works in the LPD Plus dual-extrusion technology
  • Has a 265x265x300 mm workspace
  • Has Wi-Fi, USB, and Ethernet connectivity
  • Has a blackout response system
  • Calibrates a build-platform with a capacitive displacement sensor
  • Compatible with perforated, glass, and other build platforms
  • Supports single and dual extrusion modes
  • Works with third-party filaments
  • Has built-in video streaming camera

Description

Large-volume dual-extrusion
Zortrax M300 Dual relies on the dual-extrusion LPD Plus technology to simultaneously print with base and water-soluble support filaments in a large build volume measuring 265x265x300 mm.

Fail-safe 3D printing
The M300 Dual can detect a power outage, jammed filament, and material running out. tIn each case it pauses the print and saves the exact position of the printing head. This way your work can be resumed from the same spot when the problem has been dealt with.

Interchangeable build-platforms
With a capacitive displacement sensor the M300 Dual can automatically calibrate to work with glass, perforated, or other types of build platforms. This way it’s possible to customize the printer for the project at hand.


Specification

Device features

Build volume
265 x 265 x 300 mm (10.4 x 10.4 x 11.8 in)
Nozzle diameter
0.4 (0.016 in)
Extruder
Dual material extruder with material jam detection
Extruder cooling system
Two fans cooling the extruder, radial fan cooling the print
Hotend
Dual material hotend
Platform
Heated
Material endstop
2 x Mechanical
Connectivity
Wi-Fi, Ethernet, USB
Operating system
Android
Processor
Quad Core
Touchscreen
4'' IPS 800x400
Camera
Yes
Available materials (single extrusion)
Z-ULTRAT, Z-PETG, Z-GLASS, Z-PLA, Z-NYLON
Available materials (dual extrusion)
Z-PETG, Z-PLA, Z-ULTRAT Plus, Z-SUPPORT Premium
External materials
Applicable
Support
Mechanically removed - printed with the same material as the model / Dissolvable - printed with a different material than the model
Material container
Spool
Material diameter
1.75 mm (0.069 in)
In the box
3D Printer, Side Covers, Z-SUITE, Starter Kit, 2 spools of material (Z-PETG, Z-SUPPORT Premium), 1xPerforated Plate, 1xGlass Plate, 2 spoolholders, Material Box

Printing

Technology
LPD Plus (Layer Plastic Deposition Plus) - advanced technology with the system of Dissolvable Support Structures
Layer resolution
100-300 microns (for 0.4 mm/0.016 in nozzle)
Minimal wall thickness
400 microns (for 0.4 mm/0.016 in nozzle)
Platform leveling
Automatic measurement of platform points height/Manual measurement of platform points height
Maximum printing temperature (extruder)
310°C (590°F)
Maximum platform temperature
105°C (221°F)
Ambient operation temperature
20-30°C (68-86°F)
Storage temperature
0-35°C (32-95°F)
AC input
110 V ~ 5.9 A 50/60 Hz 240 V ~ 2.5A 50/60 Hz
Maximum power consumption
400 W

Software

Software Bundle
Z-SUITE
Supported input file types
.stl, .obj, .dxf, .3mf
Supported operating system
Mac OS X / Windows 7 and newer versions
